PMX-3000 image
PMX 3000W End ViewsPMX Remote Control

PMX 3000W-PSW

Features:

  • Inverts 12V DC to 115V AC
  • MAX continuous Output Power 3000 Watt
  • Meets 120V AC electronic appliance safety operating standard.
  • It can be used to power most electronic appliances or equipment.

Specifications:

  • MAX continuous Output Power 3000 Watts
  • Peak Output Power: 6000 Watts (0.3 sec)
  • DC Input Static Current (No Load): ≤ 1.5 Amp
  • AC Output Wave Form: Pure Sine Wave
  • Low Voltage Alarm: 10.5 ± 0.5V
  • Low Voltage Cut Off Level: 10.5V
  • Auto-reset after shut-down: 12 V ±0.5V
  • High Voltage Cut Off Level: 15V-16.5V
  • Output AC Voltage: AC 115V ± 10% RMS
  • Output Frequency Level: 60 ± 1Hz
  • Overload Power Range: 3000 Watts +5-30%
  • 4 x AC Outlets (2 x GFCI)
  • USB Power Port Output V/A: DC 4.7-5.3V / 2100mA
  • Full Load Optimum Efficiency: ≥ 85%
  • AC Output Short Circuit Protection: system shut down (no damage)
  • Temperature Protection: < 65°C
  • Cooling Fan: Dependant on inner temperature rising above ≥ 45°C
  • LED Indicators: normal/Green, fault/Red
  • Remote Control Feature: Yes, available separately

PMX 001:

Remote with on/off switch and 10ft cable
